AlphaHound
This is AlphaHound.
Rugged, reliable, and repairable, AlphaHound is the perfect addition to your radiation detection toolkit. Access multiple display modes, change user settings and functions all with a simple shake.
Introducing: AB+G
The Ultimate Alpha/Beta/Gamma-Capable Radiation Detector.
Capable of Alpha/Beta/Gamma separation all while keeping a compact form factor.
Available as a drop-in Gamma Mod kit for AlphaHound A, AB & AB+.
New features/specs:
Gamma Detection & Spectroscopy (5x5x25mm BGO Scintillator)
Gamma Sensitivity: Cs-137 - 1 μSv/h = 35 cps
>50keV Gamma Energy Detection
Three independent buttons
Speaker for Radiation Clicks and Alerts
Alpha, beta & gamma separation
Spectral dose rate compensation
Limited Time - $529
Product Details
Includes
AlphaHound
Boot Dust Cover/Alpha Shield
Wrist Strap
USB Type A to C Charging Cable
Construction Materials
Chassis(SLM 316L Stainless Steel)
Dust Cover(SLS Nylon)
Operating Ranges
0 to 6,000,000 CPM | >12.0MCPM Over Range (Beta)
0 to 1.2 MCPM | >3 MCPM Over Range (Alpha)
0 to TBD MCPM | >TBD MCPM Over Range (Gamma(AB+G))
0 to 20,000 CPS | >50,000 CPS Over Range (Alpha)
0 to 100,000 CPS | >200,000 CPS Over Range (Beta)
-20°C to 45°C (-4°F to 113°F)
Measuring Units
CPM
CPS
Rem/Sv(AB+G)
Beta Energy Sensitivity
<50 KeV @ 25°C
Modes
mode 1 : Rolling Graph(All Models)
mode 2 : Sparkles(All Models)
mode 2 : Absolute/Total CPS/CPM(All Models)
mode 3 : AB Split Sparkles(AH+)
mode 4 : Basic AB 2D spectroscopy (AH+)
mode 5: Basic AB 3D spectroscopy (AH+)
mode 6 : Counts Per Hour(approximate radon levels)(All models)
mode 7 : User Settings(All models)
Mode 8 : Gamma Spectroscopy(AB+G)
Mode 9 : TBD(AB+G)
Battery Type
Lithium, Rechargeable 350mAh(User Replaceable)
Battery length on full charge
3-20hrs(Depending on display mode)
Time to full charge
1.5hr
Display Type
Digital 128X128 OLED (User Replaceable)
EMI/EMC Certification
FCC, ISED, CE, UKCA
Country of Origin
USA
Gamma Energy Sensitivity
<50 KeV @ 25°C
Gamma Sensitivity & Energy Resolution
42cps/uSv/hr(0.42cps/uRem/hr) - Cs137(AB+G)
15%+-1% - Cs137-662KeV(AB+G)
Rejection Ratios (AB+/AB+G)
Alpha to Beta: < 5%
Beta to Alpha: < 0.001% @ < 20,000 CPS(1.2MCPM)
Scintillation Materials
EJ-440(AlphaHound)
EJ-444(AlphaHound AB & AlphaHound AB+)
EJ-444 & BGO (AB+G
User Input
1 Axis Accelerometer(All Models)
Soft tactile 3 button left right middle buttons(AB+G)
Software
User updatable over USB C port with windows PC through AlphaHoundUpdater Software
Alpha/Beta detection in your pocket.
-
Compact
Pocket-sized scintillator secured in a stainless steel chassis.
-
Sensitive
With 1.72 in² of open detection area, AlphaHound helps locate contamination with ease.
-
Reliable
Equipped with an internal system check so that you will not miss a radioactive source from device malfunction.
-
Repairable
Designed to allow the user to fix the device using drop-in replacement parts.
